65 inch lcd panel full color led back light advertising signage
kiosk Outdoor Digital Signage
Specification
| Name | 65''outdoor floor digital signage |
| Panel parameter | Size | 65inch LED screen |
| Display area | 1428.48*803.52MM |
| Resolution | 1920*1080 |
| Brightness | 2000cd/m*2 |
| Color | 16.7M |
| Aspect ratio | 16:9 |
| Response time | 6.5MS |
| Contrast | 4000:1 |
| View angle | 178°/168°(H/V) |
| CPU | HD video and audio decoder chip |
| Mainboard | 40A |
| System Ram | DDR3 1Gbyte |
| System Rom | NAND FLASH 8Gbyte |
| IO connectors | 1 x USB host,1 x USB OTG,1 x serial Port,1 x I2C Interface,1 x LVDS
Interface ,1 x stereo Audio Out |
| Storage | USB/SD card |
| Decoding resolution | MAX 1080P |
| Audio | built-in HD audio 8(Realtek ALC888) audio system |
| Video format | MPEG1,MPEG2,MPEG4,H.264,WMV |
| Audio format | MP3 |
| Photo format | JPEG,BMP,PNG |
| wifi | yes |
| OS | Android 4.2.2 |
| OSD Language | Chinese, English |
| Play Mode | Supports loop playback, timed playback and other multi-player mode |
| Environment | Operating Temperature :0°C to 40°C
Storage Temperature :-20°C to 60°C
Humidity:20%-80% RH at 40°C, |
| System Power Supply | AC 110V~240V,50/60HZ |
| Power cord | Yes |
| Case | Cold rolled steel with powder coating+ toughened glass surface |
Features
| 1 .55-75 inch high brightness LCD Module, 1500-3000nits brightness,
1920x1080 resolution, 4000:1 contrast with LED backlight, Sunlight
viewable; |
| 2 . Patented LED backlight modular components + constant current
source drive components; | |
| 3 . Patented cooling structure combination of high-quality fan
assembly; | |
| 4 . Quad cores CPU 8Gb memory , Latest Android OS network version
support LAN control , WIFI control , USB , CF , SD slots , support
VGA input,3G(optional); |
| 5 . Automatic ambient light adjustment control (extended life and
energy efficiency); | |
| 6 . Built-in power adapter combination AC220V/DC; | | |
| 7 . IP65 grade all waterproof and dustproof metal enclosure +6mm
optical protective glass + air cooling/heating system; |
| 8 . Highly fortified AR glass , protect the LCD screen from direct
injury , played the role of anti-riot; | |
| 9 . Rackmount LCD display module + built-in anti-theft locks ,
patented a unique , easy to disassemble and maintain the site , a
unique patent |
| 10 . A/C automatic fans Cooling/Heating system , thickness 14cm ,
Intelligent condition monitoring,real-time detection equipment
vibration , temperature and humidity parameters such as power
supply , timely warning , Working temperature: -20℃ - 50℃; |
| 11 . Frame(fit with single side screen) can be customized exactly
same as client provided; | |
1. Q: Are you a plant or trading company?
A:We are a lcd advertising player,digital signage,lcd video wall
plant, lcd touch screen. We integrate R&D team,
manufacture,quality control team, sale and after-sale service.
2. Q: Where is your plant located? How can I visit there?
A:Our factory is located in Shenzhen, GuangDong Province, China.
About 15 minutes by car from Shenzhen airport
we pick you up there. All our clients from home or abroad are
warmly welcome to visit us!
3. Q: For the first order, can we place a advertising player, lcd
touch screen kiosk sample order?
A: Yes,of course, when you have our lcd digital signgae, lcd
advertising player, lcd video wall samples in hands,
you will know more if it is worth to move forward!
4. Q: About the quality control, how will our plant guarantee it?
A:The quality is always our priority.We have Total Quality
Management System to control quality. We have our
own professional engineer with many years’ experience. Our factory
has gained FCC, CE, RoHS etc for our lcd
video wall, digital signage, lcd advertising player
| Features: |
|
|
| Outdoor highlighting: Clearly visible in all-weather sunlight, with
a maximum brightness of 3000 nit; |
| (optional 1000nit 1500nit 2000nit 2500nit 3000nit). |
|
| Intelligent photo-sensing: The whole machine is equipped with a
photo-sensing module, the screen |
| brightness is automatically adjusted with the external brightness,
energy saving and comfortable |
| display effect. |
|
| Timing backlight: Supports timing backlight adjustment for 10
groups of time periods, convenient |
| and easy to operate. |
|
| Intelligent temperature control: The intelligent temperature
control system automatically adjusts |
| according to the temperature inside the machine. When the
temperature inside the machine exceeds |
| the allowable range, it automatically turns off the power, enters
sleep protection, the temperature |
| reaches normal values, and resumes the boot mode; the temperature
control module can maintain |
| the constant temperature inside the body Dry environment to prevent
fogging and condensation. |
|
| Dust-proof and waterproof: The airtight design of the whole machine
prevents external dust and |
| water from entering the interior and reaches IP65 standard |
|
| Sun protection and explosion protection: the shell is galvanized
cold-rolled steel plate or stainless |
| steel (optional), which is processed by baking paint, waterproof
sun protection, explosion-proof |
| professional surface technology. |
|
| Anti-reflection and anti-reflection: (optional) The front of the
product adopts imported or domestic |
| anti-glare glass, (imported is better than domestic), which can
effectively increase the internal light |
| projection, reduce the reflection of external light, and make the
LCD screen display image color more |
| vivid and bright; Conventional products are equipped with
ultra-white tempered glass as standard, |
| which does not have AR performance, but meets most needs. |
