| Camera | Resolution | 200W pixels |
| Model | binocular wide dynamic camera |
| Focusing Distance | 50-150cm |
| White Balance | automatic |
| Screen | Size | 8 inch (IPS full-view LCD display) |
| Resolution | 800*1280 |
| Processor | CPU | RK3288 quad-core / RK3399 six-core / MSM8953 eight-core |
| RAM | EMMC 8GB |
| Accessories | Fill Light | LED and IR dual fill light |
| Interface | Network Module | Supports Ethernet and Wireless (WIFI) |
| Audio | Supports 2.5W / 4R Speakers |
| USB Interface | 1 USB OTG, 1 USB HOST standard A port |
| Serial Communication Interface | 1 RS232 serial port |
| Relay Output | 1 door open signal output |
| Wiegand Interface | 1* Wiegand 26/34 output, 1* Wiegand 26/34 input |
| Upgrade Button | Support Uboot Upgrade Button |
| Wired Network Interface | 1 RJ45 Ethernet Socket |
| Function | Face Detection | supports detection and tracking of multiple people at the same time |
| Face Library Support | up to 30,000 |
| 1: N Face Recognition | support |
| 1: 1 Face Comparison | support |
| Stranger Detection | support |
| Identify Distance Configuration | support |
| UI Interface Configuration | support |
| Remote Device Upgrade | support |
| Device Interface | Interfaces include device management, personnel / photo management,
record query, etc. |
| Deployment Method | support public cloud deployment, privatized deployment, LAN use,
stand-alone use |
| Infrared Thermal Imaging Module | Human Temperature Detection | support |
| Temperature Detection Distance | 1 meter(optimal distance 0.5 meter) |
| Temperature Measurement Accuracy | ≤ ± 0.5 ℃ |
| Temperature Measurement Range | 10 ℃ ~ 42 ℃ |
| Thermal Field of View | 32 X 32 ℃ |
| Visitors' Temperature is Normal and Released Directly | support |
| Body Temperature Over Temperature Alarm | support (body temperature alarm value can be set) |
| General Parameters | Protection Class | IP65, certain outdoor dustproof and waterproof function |
| Power Supply | DC12V (± 10%) |
| Operating Temperature | ﹣10 ℃ ~ 60 ℃ |
| Storage Temperature | -20 ℃ ~ 60 ℃ |
| Power Consumption | 13.5W (Max) |
| Installation Method | gate bracket installation |
| Size | 274.24 * 128 * 21.48 (mm)
IC card/ID card:296.18*132.88*25(mm) |
| Net Weight | 1.45kg |
